The 3+4+5 axle combination of modular trailer means that different numbers of axle modules are configured at the front and rear, forming a large transport platform with a total of 12 axles. Goldhofer modular trailer for sale is more suitable for transporting equipment weighing tens to hundreds of tons or even more.
The biggest advantage of the 3+4+5 axle Goldhofer trailer is its versatility. Users can select different numbers of axle modules based on the weight, length, and width of the cargo, using longitudinal connections or transverse parallel combinations. For example, the number of axles can be reduced for light transport tasks, while more axle modules can be added for transporting very large equipment. This flexibility helps transport companies reduce equipment investment and improve vehicle utilization.
Name: Goldhofer Trailer
Dimension: 22812mm*3000mm*1080(+280/-280)mm
Usage: Transport bridge and heavy duty cargo
Max Payload: 275 tons
Tires: 96 units
Suspension type: Hydraulic lifting steering
Landing gear: Front and rear hydraulic support cylinder
King pin: 2.00 or 3.5 inch bolt-in king pin
The 3+4+5 axle combination increases the number of axles, distributing cargo weight evenly across more wheels, significantly reducing pressure on individual axles and the ground, and improving transport safety. Each additional axle can support greater weight while reducing concentrated loads on roads and bridges. Therefore, this combination is particularly suitable for transporting heavy cargo such as large industrial equipment, steel structures, power generation equipment, and mining machinery. The Goldhofer modular trailer for sale features a modular design, allowing for flexible combinations of different axle numbers to adapt to various transport tasks.
Goldhofer trailer typically employ a hydraulic suspension structure, allowing each axle to rise and fall independently, enabling the vehicle to automatically adapt to different road conditions. When encountering potholes, slopes, or bridge connections, the hydraulic system adjusts the platform height to maintain cargo stability. Simultaneously, the hydraulic suspension effectively reduces impacts during transport, improving the safety of transporting large, precision equipment.
The 3+4+5 axle modular trailer for sale is widely used in the energy, petroleum, mining, construction, and infrastructure industries. Examples include transporting wind turbines, pressure vessels, transformers, large steel structures, and bridge modules. These types of transportation tasks are typically high-value and heavy, requiring extremely high vehicle reliability, safety, and precise handling capabilities. Therefore, high end modular trailer for sale has become an important piece of equipment for large transportation companies.
